Unisystem is more than just a standard or customized solutions. Our offer includes several products with very specific configuration. All models described below can work in the industrial temperature range: -20 to +70 degrees Celsius.
Unusual square TFT LCD display with dimensions 71.93 x 71.93 mm and 720×720 resolution using the RGB interface is a product form the Multi-Inno. The module (MI0400KT-1CP) has been equipped with a capacitive touch panel and FT6336U controller allowing the use of the I2C interface. It has applied the décor glass with a hardness of 6H.
The WF24LTYAJDNN0# model is a 2.4-inch display with a resolution of 240×320 pixels. The IPS matrix used in it allowed to obtain wide viewing angles both horizontally and vertically (80 degrees). The integrated ILI9341V controller allows the use of the MCU8080 or SPI interface. The display has a vertical orientation and a brightness of 500 cd/m2. Optionally, it can be equipped with a resistive touch panel.
Another interesting product (WF40CTYAQMNN0#) is a vertically oriented display with an unusual size of 3.97 inches. This model from the Winstar range has also been equipped with an IPS matrix with wide viewing angles and offers brightness of 600 cd/m2. Built-in ST7701S controller supports the MIPI DSI interface.
The table below presents the most important technical parameters of described products:
| MI0400KT-1CP | WF24LTYAJDNN0# | WF40CTYAQMNN0# | |
| Matrix type | TFT | IPS | IPS |
| Size | 4 inch | 2.4 inch | 3.97 inch |
| Resolution | 720 x 720 RGB | 240 x 320 RGB | 480 x 800 RGB |
| Interface | MIPI | MCU8080, SPI | MIPI DSI |
| Controller | YY1821 | ILI9341V | ST7701S |
| Brightness | 300 cd/m2 | 500 cd/m2 | 600 cd/m2 |
| Touch panel | CTP | RTP (option) | None |
| Active area | 71.93 x 71.93 mm | 36.72 x 48.96 mm | 51.84 x 86.4 mm |
| Outline dimensions | 84 x 84 x 2.56 mm | 42.72 x 60.26 x 2.8 mm | 57.14 x 96.85 x 2.15 mm |
Above models are perfect for applications requiring unusual sizes or above-standard readability of the display, i.e. in portable medical devices, controllers, thermostats or smart home applications.
