WEO001602BWPP5N00000 – Winstar Longlife OLED alphanumeric display

This module can operate in a stable and failure-free way for a long period within wide range of temperatures. Thanks to such option, it may be successfully applied e.g. in transportation and automotive industry.

The main difference between LCD and OLED technology is a matter of light generating. Standard LCD panel requires backlight to illuminate its pixels and thus displayed image. Whereas in OLED technology, pixels themselves are a source of emitted in appropriate color light.

LCD module backlight causes that obtained blackness is never perfect because part of the light breaks through the matrix. This feature becomes particularly clear in a dark room. On the other hand, OLED technology makes possible complete disconnection of selected pixels, so that the cell emits 0 cd/m2 achieving an effect of perfect blackness. Perfect blackness and comparable to LCD brightness result in much higher contrast and readability. Depending on the external lighting, static contrast of OLED screen is from 2000: 1 to infinity, reaching the highest possible value in today's technology.

Displays with Chip on Glass characterize with smaller thickness of all outer dimensions and thanks to more hermetic construction they are tighter and more shock-resistant. Additionally, they are more price-attractive and have lower power consumption.

OLED screens characterize with faster response time in comparison to LCD matrixes. LCD display reaction time is in range between a few to even several hundred milliseconds and results from liquid crystal properties. On the other hand, the response time of OLED modules is less than 10 μs. LCD response time rapidly grows in below-zero temperatures and it may even cause a complete stop of displayed content or at least ghosting. OLED displays do not have this failure and run at full speed even in temperature of -40 °C.

In OLED displays each pixel emits individually light just by the surface, so that the displayed image is completely readable from any viewing angle. To compare, in LCD technology light-emitting layer is located from below and on this layer, there is applied light transmissive and color filtering matrix. Created in such display image characterize with very good optical parameters only when you look at it from right angle. Any different viewing angle results in lower light transmission. This causes a visible deterioration of image quality that is reflected in brightness and contrast decrease.

All standard Winstar OLED displays have built-in 4 sets of fonts: English, European, Japanese and Cyrillic. Thanks to usage of many languages, this solution extends the range of applications on various markets. Selected characters from the extended set of fonts can also be used by application developers as icons. Additionally, embedded fonts significantly speed up applications development in graphic displays. There is no need to design and program own fonts as user can just choose and apply a suitable one.

The history of OLED displays is relatively short. Initially, the main drawback of this technology was a short life span of OLED cells (especially for blue color) which significantly narrowed scope of applications. Conducted research eliminated this obstacle. Currently, contrary to popular beliefs and myths, OLED technology is so refined that it can be successfully used in industrial applications. At present, OLED displays surpass LCD modules in all respect and their liveliness varies from 50 000 to 110 000 hours (depending on the color).

Thanks to using special organic material, OLED technology enables automatic generation of light. OLED panel does not require backlight and consumes only as much energy as need lit at the time pixels. With this solution, the average OLED power consumption is much lower in comparison to LCD panel with standard backlight.
