VisionCB-6ULL-STD
Mass production? Register →
| Ports | RGB LCD - 1, USB Console - 1, USB Host - 1, USB OTG - 1, Ethernet - 1 |
| Special | 5 Pushbuttons, 5 LEDs, Boot selector, Arduino Uno Rev. 3 compatible, Raspberry Pi compatible |
| Voltage | 5V DC, 9-12V DC |
| Interface | Bluetooth, eMMC, I²C, RGB, USB, Ethernet, UART, Wi-Fi |
| Manufacturer | SoMLabs |
| Operating temp. (°C) | 0 ~ 70 |
The VisionCB-6ULL-STD is a versatile carrier board designed for VisionSOM-6UL and VisionSOM-6ULL modules, offering a complete development platform for industrial embedded applications. Powered by NXP i.MX 6UL/6ULL ARM Cortex-A7 processors, the VisionCB-6ULL-STD features SODIMM200 interface, Ethernet 10/100, USB Host, USB OTG, and a 50-pin RGB LCD connector supporting up to 1366×768 resolution. With Arduino Uno Rev. 3 and Raspberry Pi compatible headers, this board is ideal for IoT developers and industrial automation projects. The VisionCB-6ULL-STD includes 5 user pushbuttons, 5 LEDs, and a boot selector for flexible configuration. Operating from 9-12V DC or 5V DC, it supports 0~70°C temperature range, making it perfect for HMI, POS terminals, smart home, and robotics applications.
