We extend Unisystem’s offer with subsequent BOE’s display solution – a 55-inch LCD (DV550FHM-NV8) destined to indoor applications, e.g., digital signage.
DV550FHM-NV8 can be used only in interior devices due to the values of crucial parameters such as brightness (500 cd/m2) or operation temperature (0-50°C). It provides perfect readability of presented content in each perspective thanks to the wide viewing angle (89°/89°/89°/89°).
This model is upgraded with local dimming which adapts the LED-backlight to the displayed picture, enhancing the difference between dark and bright areas. It provides a faithful color reproduction by improved contrast (in DV550FHM-NV8 the contrast has been estimated at 45000:1 with local dimming and 1200:1 without local dimming). Moreover, this effect is achieved with a simultaneous reduction of power consumption.
We present the crucial parameters of DV550FHM-NV8 in the table:
| size | 55” |
| resolution | 1920×1080 |
| active area | 1209.6(H)x680.4(V) mm |
| brightness | 500 cd/m2 |
| contrast ratio | 45000:1 |
| viewing angle | 89°/89°/89°/89° (IPS) |
| surface treatment | anti-glare, Haze 25%, 3H |
| backlight | LED |
| LED lifetime | 30 000 h |
| interface | LVDS |
| response time | 8 ms |
| power consumption | 175 W |
| outline dimensions | 1213.5(H)x684.3(V)x40.9(D) mm |
| weight | 15 800 g |
| operation temperature | 0-50°C |
| special features | local dimming |
DV550FHM-NV8 can be used in selected digital signage applications, e.g., in transportation as passenger information carriers. It is worth noticing that this model of 500 cd/m2 brightness cannot be applied in intensely lighted locations. Hence it should be mounted rather in the underground passageways leading to platforms or stops than in the glass-panelled halls of stations.
What is more, this model can be used in various information kiosks or totems. Usually, such applications require a touch panel as they are operated by gestures. At Unisystem, we can combine DV550FHM-NV8 with a touch sensor – contact us to get more details. In the case of devices located in public spaces, the other improvements might be necessary as cover glass preventing mechanical damages or, e.g., anti-shatter coating (AS) limiting the spreading of glass splinters while the module is smashed (learn more about coatings – here).
Find out other solutions by BOE in Unisystem’s offer, e.g., 1.2-meter smart shelf designed for retail.
2020-07-28
