New 15.6-inch LCD-TFT from Winstar – HD matrix with high brightness for professional applications

New 15.6-inch LCD-TFT from Winstar – HD matrix with high brightness for professional applications

The market for professional electronic equipment is constantly growing, and with it the requirements for the components used are increasing. Displays play a particularly important role here, as they largely determine the functionality of the entire device. Therefore, matrices that combine high resolution, brightness, contrast and viewing angles with resistance to harsh working conditions are in demand.

Winstar’s answer to these needs is a new 15.6-inch LCD-TFT, designated WF1560BSYAA5ENN0, which has just been added to Unisystem’s product line. The matrix is made with IPS technology, so images are displayed with similar quality, saturation and sharpness regardless of the viewing angle. Combined with a high Full HD resolution (1920 x 1080 pixels) and a brightness of 1,000 nits, we can be sure that the display will perform well in harsh outdoor lighting conditions.

Key parameters of the WF1560BSYAA5ENN0 display:

When looking for a matrix for professional electronic equipment, look out for a new 15.6-inch LCD-TFT display designated WF1560BSYAA5ENN0 from Winstar. Above all, it is characterized by a very high brightness of up to 1,000 cd/m2, which ensures a clear and crisp image even in difficult lighting conditions. Communication with the matrix is done through a high-speed eDP interface (commonly used in laptops, tablets, smartphones). The eDP communication protocol provides wide data bandwidth, easy integration with other components, and simplifies the design process of the end device. while the dedicated TC2055G control chip optimizes the operation of the display and increases the stability of the entire module.

  • Diagonal: 15.6 inches
  • Resolution: 1920 x 1080 pixels RGB (Full HD)
  • Active area: 344.16 x 193.59 mm
  • Module dimensions: 360.0(W) x 212.3(H) x 9.0(D) mm
  • Brightness: 1000 cd/m2
  • Static contrast ratio: 1500:1
  • Viewing angle: 80/80/80/80° (IPS)
  • Interface: eDP
  • Control chip: TC2055G
  • Power supply: 3-3.6 V DC
  • Operating temperature: -20°C to +70°C

Professional applications of the WF1560BSYAA5ENN0 display.

Thanks to its parameters, the WF1560BSYAA5ENN0 display will be perfect for demanding professional applications. Potential areas of use include:

  • Industrial inspection and measurement equipment for harsh lighting conditions
  • Digital signage and outdoor billboards
  • Monitors for demanding gamers
  • Specialized medical devices
  • POS terminals for stores and service outlets
  • Vending machines and ticket machines
  • Mobile dashboards

In industry, it can be used in specialized control and measurement equipment, operator desktops for production equipment or mobile terminals used during logistics processes. Its high brightness and contrast will provide a clear image even in difficult lighting conditions on the shop floor or outdoors.

Another area of application is various types of digital boards, used both indoors (e.g., in shopping malls) and outdoors (billboards, citylights).

Due to its fast matrix response, this display will also be great for computer monitors for demanding gamers, providing smooth and sharp images even in dynamic games or movies. It can also be successfully used in professional medical devices, where accurate image reproduction is crucial.

Other potential application areas include POS terminals, ATMs, vending machines or mobile operator desktops. Wherever functionality, reliability and quality of the displayed image matter.


The new 15.6-inch LCD-TFT WF1560BSYAA5ENN0 from Winstar is an interesting proposition for manufacturers of professional electronic equipment. It combines high image resolution, ultra-high brightness of 1,000 nits, wide viewing angles and a reinforced design to withstand harsh working conditions. Thanks to its proven IPS matrix, it also provides accurate and consistent color reproduction. Such a wide range of functionality makes the WF1560BSYAA5ENN0 display ideal for a variety of professional applications – from industrial measuring devices to medical monitors to digital signage or ticket vending machines. If you want a reliable display with high image quality, this is a proposal worth considering.
